micro3-三脚插片保险丝-5-132v
产品信息
产品类别：车用保险丝|直流保险丝
关键词：micro3-三脚插片保险丝-5-132v
点击率：
发布时间：2019-08-16 15:28:41
全国服务热线：13549460265
产品详情
micro3™ blade fuses rated 32v
the micro3™ fuse has 3 terminals and 2 fuse elements with a common center terminal.
time-current characteristic curves
the micro3™ fuse has 3 terminals and 2 fuse elements with a common center terminal.
its sub-miniature design meets the need for more circuits to be protected while utilizing less space and its ability to cope with high temperatures in adverse environments makes the micro3™ fuse of recommended choice for protection.
physical view
dimensions in mm
time-current characteristics
|
% of rating |
opening time (min / max) |
|
110 |
100 h / – |
|
135 |
0.75 sec / 120 sec |
|
160 |
0.30 sec / 50 sec |
|
200 |
0.15 sec / 5 sec |
|
350 |
0.04 sec / 0.50 sec |
|
600 |
0.02 sec / 0.100sec |
ratings
|
part number |
current rating (a) |
housing material color |
typ. voltage drop (mv) |
cold resistance (mω) |
i2t (a2s) |
|
0337005._ |
5 |
orange |
116 |
17.4 |
17 |
|
033707.5_ |
7.5 |
tan |
106 |
10.8 |
47 |
|
0337010._ |
10 |
red |
102 |
7.8 |
89 |
|
0337015._ |
15 |
blue |
94 |
4.9 |
189 |
temperature rerating curve
采购：micro3-三脚插片保险丝-5-132v
