汽车插件保险丝fky-293
产品信息
产品类别：车用保险丝|直流保险丝
关键词：保险丝,保险丝座,汽车保险丝,汽车保险丝座,温度保险丝,温控开关,电流保险丝,车用保险丝,车用保险丝座,热敏电阻,压敏电阻,过载保护器,自恢复保险丝,贴片保险丝,高压保险丝
点击率：
发布时间：2019-07-02 09:54:12
全国服务热线：13549460265
产品详情
| 汽车插件保险丝fky-293,汽车保险丝，车用保险丝 |
|
description
pal fuses are commonly found on many japanese and domestic built vehicles.
voltage rating: 32 vdc
current cycling: 24˚c
the fuses satisfy the performance requirements after 50% of the rated current is applied for 10,000 cycles. each cycle consists of an interrupted current with the pattern of 5 minutes on and 10 minutes off.
operating temperature range: -40˚c to 125˚c
complies with jaso 0612
time-current characteristics
| % of rating | opening time min / max (s) |
| 110 | 14,400 s |
| 200 | 5 s / 100 s |
| 350 | 0.2s / 7 s |
| 600 | 0.040 s / 1 s |
ratings
| part number current | rating (a) | body color |
| fky29320 | 20 | light blue |
| fky29330 | 30 | pink |
| fky29340 | 40 | green |
| fky29350 | 50 | red |
| fky29360 | 60 | yellow |
| fky29370 | 70 | brown |
| fky29380 | 80 | black |
| fky293100 | 100 | blue |
采购：汽车插件保险丝fky-293
